69MPa Ultra High Pressure Thermoplastic Hose

The 69MPa Ultra High Pressure Thermoplastic Hose is designed for high-pressure fluid transfer in industries like cleaning and hydraulics. With nylon inner, steel wire reinforcement, and polyurethane outer, it offers durability and safety.
INQUIRY EMAIL

I.D.			O.D.	W.P.		B.P.		MIN.B.R.	W.T.
Dash	In.	mm	mm	MPa	psi	MPa	psi	mm	g/m
-4	1/4	6.3	15	69	10000	207	30000	110	255
-5	5/16	7.9	17	69	10000	207	30000	130	310
-6	3/8	9.5	19	69	10000	207	30000	150	375
-8	1/2	12.7	22	69	10000	207	30000	200	570

Our 69MPa Ultra High Pressure Thermoplastic Hose is engineered to withstand the toughest conditions, offering outstanding durability and performance. This high-quality hose is perfect for high-pressure applications such as water and hydraulic fluid transfer, particularly in industries like high-pressure cleaning, construction, and more.

Key Features:

Inner Liner: Made from high-quality nylon, ensuring excellent resistance to pressure and wear.
Reinforcement: Four layers of steel wire braiding provide exceptional strength and flexibility, making this thermoplastic hydraulic hose ideal for high-pressure environments.
Outer Cover: The hose is coated with a black or colored polyurethane outer layer that enhances durability and resistance to abrasions, chemicals, and UV exposure.
Temperature Range: This hose operates effectively in temperatures ranging from -40°C to +100°C (-40°F to +212°F), making it suitable for both cold and hot environments.
High Pressure Rating: With a working pressure of up to 69MPa, this hose excels in demanding applications where reliability and performance are critical.

Applications:

This high-pressure thermoplastic hose is widely used in industries requiring the transportation of fluids such as water and hydraulic oils under extreme pressure. Key applications include:

High-pressure washing: Efficient water transfer for industrial cleaning.
Hydraulic systems: Ideal for hydraulic fluid transfer in construction and machinery operations.
Industrial fluid handling: Perfect for environments where high strength and low friction are essential.

Why Choose Our Thermoplastic Hydraulic Hose?

Durability: The four-layer steel wire reinforcement ensures the hose’s robustness and longevity in demanding environments.
Versatility: Ideal for use in various industries, including construction, cleaning, and more.
Non-conductive: Suitable for both non-conductive hydraulic hose fittings and electrical safety applications.
Easy to Install: Compatible with thermoplastic hose fittings and accessories that ensure secure, leak-free connections.
Global Reach: Our hoses are trusted by customers worldwide for their exceptional quality and reliable performance.

Product Advantages:

Superior Performance: Designed for extreme high-pressure applications, this hose delivers excellent performance, even in the most challenging conditions.
Safety & Reliability: With thermoplastic high-pressure hose technology, you get a hose that not only performs well but also ensures your safety, withstanding high pressure and heavy-duty environments.
Quality Materials: Constructed with durable nylon and polyurethane materials, this hose resists wear, chemicals, and environmental stress, extending the life of your equipment.

Temperature & Pressure Range:

Temperature: -40°C to +100°C (-40°F to +212°F)
Maximum Pressure: 69MPa (10,000 psi)

FAQ

Q1: Can this hose handle high-pressure washing applications?
Yes, the thermoplastic pressure washer hose is specifically designed to handle high-pressure water transfer, making it an excellent choice for industrial cleaning.

Q2: Is this hose compatible with non-conductive hydraulic systems?
Absolutely! Our non-conductive hydraulic hose is ideal for applications where electrical conductivity must be avoided.

Q3: What fittings do I need for this hose?
We offer a full range of thermoplastic hose fittings and non-conductive hydraulic hose fittings to ensure secure, reliable connections for your hose assembly.
