EN853 1SN:-40°C To +150°C
INNER RUBBER LAYER: Black hydrogenated nitrile rubber with excellent heat and aging resistance
REINFORCEMENT LAYER: One layer of steel wire braiding
OUTER RUBBER LAYER: Blue synthetic rubber with high temperature, ozone, andwear resistance
OPERATING TEMPERATURE:-40°C to +150°C(-40°F to +302°F)APPLICABLE MEDlA: Air, water, oil and gas mixture, oil-based or water-based hydraulic oil
APPLICATION SCOPE: Transportation of air, water, and oil-gas mixture under high temperature.It is widelyused in construction, mining, plastic machines, air compressors,and other industries.
| Hose Size | I.D | O.D | MaxW.P | Min B.P | Min B.R | W.T | ||||||
| mm | inch | Min | Max | Min | Max | MPa | Psi | MPa | Psi | mm | kg/m | |
| 6.3 | 1/4 | 6.1 | 6.9 | 12.7 | 13.7 | 22.5 | 3260 | 90.0 | 13050 | 75 | 0.12 | |
| 8 | 5/16 | 7.7 | 8.5 | 14.3 | 15.3 | 21.5 | 3120 | 86.0 | 12325 | 85 | 0.14 | |
| 10 | 3/8 | 9.3 | 10.1 | 16.6 | 17.6 | 18.0 | 2610 | 72.0 | 10440 | 90 | 0.22 | |
| 12.5 | 1/2 | 12.3 | 13.5 | 19.7 | 20.7 | 16.0 | 2320 | 64.0 | 9280 | 130 | 0.25 | |
| 16 | 5/8 | 15.5 | 16.7 | 22.7 | 23.9 | 13.0 | 1885 | 52.0 | 7540 | 150 | 0.27 | |
| 19 | 3/4 | 18.6 | 19.8 | 26.8 | 28.0 | 10.5 | 1520 | 42.0 | 6090 | 180 | 0.35 | |
| 25 | 1 | 25.0 | 26.4 | 34.6 | 35.8 | 8.8 | 1280 | 35.0 | 5075 | 230 | 0.52 | |
| 31.5 | 1-1/4 | 31.4 | 33.0 | 43.6 | 44.8 | 6.3 | 910 | 25.0 | 3625 | 420 | 1.18 | |
| 38 | 1-1/2 | 37.7 | 39.3 | 50.9 | 52.1 | 5.0 | 725 | 20.0 | 2900 | 500 | 1.42 | |
| 51 | 2 | 50.4 | 52.0 | 64.1 | 65.5 | 4.0 | 580 | 16.0 | 2320 | 630 |
1.90 |
|
The SAE 100RAT EN853 1SN High-Pressure Steel Wire Braided Reinforced Hydraulic Hose is engineered for robust, high-pressure applications, ideal for industrial and hydraulic systems. Built to DIN EN 853 1SN standards, this hose guarantees reliable performance under extreme conditions, ensuring safe and efficient fluid conveyance.
Constructed with high-quality steel wire braiding reinforced, this EN853 1SN hydraulic hose offers superior resistance to abrasion, corrosion, and high temperatures, making it suitable for demanding environments. Its steel wire braiding also enhances durability and pressure capacity, providing optimal support in high-pressure systems.
Designed to meet both EN 853 1SN and DIN 20022 standards, our EN853 1SN high-pressure hose ensures compatibility with a range of hydraulic systems, delivering stable and leak-free operation. The product complies with standards like Hypress EN 853 DIN 20022 and TS 6387 EN 853 1SN, reflecting its versatility and reliability in various industrial applications.
Choose this EN 853 1SN steel wire braided reinforced hose for long-lasting performance, reliability, and safety in high-pressure hydraulic systems. Whether you’re looking for durability or high performance, this hydraulic hose is engineered to meet the highest standards for diverse industrial needs.
