The 1 1/4 high pressure hose is designed for industrial and hydraulic applications requiring high performance and durability. Below, we provide the technical parameters and specifications to help you better understand its capabilities and make an informed decision.
| Parameter | Details |
|---|---|
| Inner Diameter (ID) | 1 1/4 inch (31.75 mm) |
| Outer Diameter (OD) | Varies based on reinforcement, typically 1.6 - 1.9 inches (41 - 48 mm) |
| Maximum Working Pressure | 3000 PSI (206 Bar) |
| Burst Pressure | Up to 12,000 PSI (827 Bar) |
| Reinforcement Layers | 2 to 4 layers of high-tensile steel wire braid |
| Temperature Range | -40°C to +120°C (-40°F to +248°F) |
| Hose Material | Synthetic rubber for inner tube, abrasion-resistant outer cover |
| Fittings Compatibility | 1 1/4 hydraulic hose fittings, including BSP, JIC, and NPT |
| Fluid Compatibility | Suitable for hydraulic oil, water-based fluids, and petroleum-based fluids |
| Minimum Bend Radius | 12 inches (305 mm) |
| Weight | Approx. 2.5 - 3.5 kg/m (varies by reinforcement) |
Ready to invest in a high-quality 1 1/4 high pressure hose? Get in touch with us for quotes, customization, or technical inquiries. Our team is here to help you find the perfect solution for your hydraulic systems!
