Verified Manufacturer Automatic 1/4-2 4SP Hydraulic Pipe Hose Crimping tool crimper Excavator Hose Press Crimping Machine

Production Capabilities:

HZ150 crimping machine is ideal for crimping hydraulic hoses up to 2" 1/4 six spirals and industrial hose up to 6" (with special dies).



Benefits:

- Three operation modes: manual, semi-automatic and full-automatic

-7-inch touch screen, - Set the buckle size - Set the opening amount

- Set error compensation

- Set pressure holding time

- It can store buckle programs



Features:

- dispenser with patented quick change tool equipped

- Famous Brand PLC control with 7'' color touch-screen display; Double speed operation

- self lubricating moving components;

- silent pump Low Noise

- "6 o'clock fixed position" of the die for greater stability of the hose during crimping;

- particularly narrow crimping head to crimp hose ends with large flanges or 90° fittings; It is convenient to buckle the special-shaped elbow

- protractor for orientation fittings;

- hydraulic power pack included.

- High capacity , Accurate, Step on the joint to save time



Some Applications Include:

It is specially used by professional assembly personnel in hose batch production, OEM hose assembly workshop and large maintenance activities. It can be used when high speed production is needed.

Technical specifications
Crimping Range:	6-51mm 1/4-2" 4SP(Customed Production Capabilities)
Dies Quantity:	11set 14 18 21 26 30 34 38 45 50 57 65(special Dies: optional)
Accuracy:	0.01mm
Swept Volume:	10L
System Pressure:	31.5MPA
Output of pump:	14L/min
Motor Power (as your requirements):	4KW(optional)
Voltage (as your requirements):	220V 50HZ 1Phase/380V 50HZ 3Phase (can customize)
Buckling Pressure:	650T
Oil Quantity:	110L
Efficiency:	250pcs/h
Strock Time:	12+2S
Package Dimension:	780*880*1450MM
Net Weight:	1050KG
Gross Weight:	1080kg
Range	±60mm
Maximum Open Diameter:	150MM
Quickly Change Ststem:	including
Foot pedal:	included
light:	included
Special Dies:	optional



Product Description

Promise
We will provide a guarantee to keep the machine in good repair within 12 months from the day when the machine is purchased. All fitting troubles will be free of charge repaired (or replaced if necessary) during the guarantee period. The damage resulted from improper use o accident damage does not belong to free of charge repair range.

Product Progress

Certification

Company Strength

 1. What level of service do you provide ?

*Your inquiry will be replied in 24 hours.

*Eight continuous years as an Alibaba Gold supplier and more than 25 years industrial technology and manufacturing experience .

* We offer free spare parts and service within 14 month warranty period.

* Technology Support by providing operation training videos .

* Professional after-sales service team.

* Give reasonable offers with the best quality.


2. What is our advantages?

* Competitive price: We can meet your budget and best-selling business very well.

* OEM Accepted: We can produce customized design.

* Good Service: We treat clients as friends and provide problem solving anytime you need.

* Good Quality: We have strict quality control system. Good reputation in the market.

* Fast & Delivery: We have big discount from forwarder (Long-term Contract).

* Door To Door Service.


3.  Can you customize the machine for the customer?

Yes. We can, we also provide OEM for customers; If you need customized services, please contact us


4.  What is the MOQ?

We usually provide 1 set for customers to test.
