| Product Parameters | |
| Crimping&Skiving Range (Inner Diameter) | 6~51mm ( 1/4~2" ) |
| Free Dies | 10 Sets of dies |
| Item No. of dies | 15.19.23.26 length 60mm 31.36.41 length 70mm 47.55.60 length 80mm |
| Accuracy | 0.01mm |
| Volume of oil tank | 2.5L / 5L / 10L (Optional) |
| System Pressure | 26MPa / 31.5MPa(Optional) |
| Motor Power | 3kW / 4kW 1 2 3 phase |
| Voltage | 220V-415V 50/60Hz |
| Buckling Pressure | 500T |
| Efficiency | 200pcs/h |
| Maximum Open Diameter | 114mm |
| The max open tolerance | ± 30mm |
| Control system | Electric Automatic |
| Control model | Micro control with Button control with pedal |
| Hydraulic oil | 46# |
| Net Weight | 310KG |
| Gross Weight | 320KG |
| Package Dimension | 1070*640*1150 mm |
